PROLIGHTS MINIECLIPSE

PROLIGHTS MINIECLIPSE

Numéro d'article : 01455

Projecteur LED

LIGHT SOURCE

Source: 28W CREE LED
CCT: (TU) 3.000 K – (DY) 5.700
Luminous flux: (TU) (19°) 563 lm – (26°) 554 lm – (36°) 582 lm – (50°) 552lm @full
Luminous flux: (DY) (19°) 731 lm – (26°) 729 lm – (36°) 743 lm – (50°) 693 lm @full
Lux: (TU) (19°) 330 lx – (26°) 180 lx – (36°) 96 lx – (50°) 51lx @5 m full
Lux: (DY) (19°) 397 lx – (26°) 212 lx – (36°) 107 lx – (50°) 52lx @5 m full
CRI: (TU) >92; (DY) >80
TLCI: (TU) >90; (DY) >68
TM30 Rf: (TU) >90; (DY) >79
TM30 Rg: (TU) >97; (DY) >97
Source life expectancy: > 70.000 hrs (L70B10 @Ta 25° C / 77° F)

OPTICS

Beam angle: optional profile lens 19° / 26° / 36° / 50° (gobo holder included) – wash zoom lens 15°-30°/ 25°-50°
Lens type: high-quality glass lens optics

DYNAMIC EFFECTS

Fixed gobos: gobo holder included in optics
Gobo size: E, outer: 37,3 mm – image: 24 mm – thickness: 1,1 mm
Manual mode: manual adjustment of dimmer and strobe

BODY

Body: sturdy die-cast aluminium body
Body colour: RAL 9003

CONTROL

Protocols: W-DMX
DMX channels: 1 / 2 / 5channel
Wireless Control: included, wireless solution receiver
Display: LCD display
Firmware upgrade: yes, via USB – DMX interface (UPBOXPRO/UPBOX1) not included

ELECTRONICS

Dimmer: linear 0 ~ 100% electronic dimmer
Dimmer curves: 4 selectable dimming modes available
Strobe / shutter: 1 – 25 Hz, electronic
Operating temperature: -20° C / +45° C (-4° F / +113° F)
LED Control: flicker free operation
Selectable PWM: 600 ~ 25.000 Hz

ELECTRICAL

Mains power supply: 100-240V – 50/60Hz
Max power consumption: 22W
Power factor: >0,40

PHYSICAL

IP rating: 20
Cooling: passive cooling and fan-free
Suspension and fixing: track-adapter included for suspension and fixing
Power connection: track adaptor (EUTRAC, STAFF, GLOBAL, IVELA, Eurostandard Plus compatible)
Dimensions (WxHxD): 112x229x226mm / 4.41”x9.02”x8.9”
Weight: 1kg / 2.2lbs

CERTIFICATIONS / APPROVALS

Certifications / Approvals: CE, UKCA, RCM
